CODESYS EtherCAT Master SL Article no. 2303000018
The CODESYS Control Linux ARM SL is an adapted CODESYS
runtime system for Linux/ARM-based platforms. The performance of the runtime
system is almost arbitrarily scalable via the hardware properties of the
system.
To install the product on the Linux OS via the CODESYS
Development System, use the the included CODESYS Deploy Tool plug-in. After
each restart the runtime system will be started automatically. If no valid full
license can be found, CODESYS Control runs for two hours without functional
limitations before shut down.
After installing the runtime environment, the PLCnext
controller can be programmed as a PLC with the CODESYS Development System.
Benefits
The runtime system supports numerous I/O interfaces, such as
discrete inputs and outputs or fieldbus adapters, as well as integrated IEC
61131-3 protocol stacks. The fieldbuses are configured directly in the CODESYS
Development System without using any additional tools.
Communication with the CODESYS Development System for
programming and debugging of the IEC 61131-3 application
Execution of controller functions and generation of graphical
user interfaces
Operation of I/O systems and fieldbuses
Detailed information can be found in the CODESYS Online Help.
Performance
CODESYS Multicore is included as full version in the delivery
of the runtime package.
Options
The runtime package can be extended by the following
products:
Fieldbus support
CODESYS CANopen Manager SL
CODESYS EtherCAT Master SL
CODESYS EtherNet/IP Scanner / Adapter SL
CODESYS Modbus TCP Master / Slave SL
CODESYS Modbus Serial Master / Slave SL
CODESYS PROFINET Controller / Device SL
Communication
CODESYS BACnet SL
CODESYS IIoT Libraries SL
CODESYS KNX SL
CODESYS OPC UA Server SL
CODESYS OPC UA Client SL
CODESYS OPC UA PubSub SL
Motion
CODESYS SoftMotion SL
CODESYS SoftMotion CNC+Robotics SL
CODESYS SoftMotion Light SL
Redundancy
CODESYS Redundancy SL
Visualization
CODESYS WebVisu SL
