CODESYS OPC UA Client SL Article no. 2302000042
The CODESYS
OPC UA Client can be used to connect to any OPC UA servers and exchange data
with them. The client provides an API to connect to an OPC UA server and
execute the different kind of OPC UA requests.
The OPC UA
Client API supports the following services:
Discovery: -
GetEndpoints - FindServers - FindServersOnNetwork
Session: -
CreateSession - ActivateSession - DeleteSession
View: -
Browse - BrowserNext - RegisterNodes - UnregisterNodes - TranslateBrowsePathsToNodeIds
Attribute: -
Read - Write
Subscription:
- CreateSubscription - MofifySubscription - SetPublishing - Publish (Handled by
the Runtime itself) - DeleteSubscription
MonitoredItems:
The client is able to handle both types of monitored items (event and
sampling). The only difference in handling is the callbacks that are called for
both types. - CreateMonitoredItems - DeleteMonitoredItems -
ModifyMonitoredItems - SetMonitoringMode
Security:
The OPC UA client uses the existing security related runtime interfaces to
handle the encryption algorithms and certificates. The client registers itself
to the certificate store for easy configuration of the client certificates.
SecurityProfiles:
- None - Basic256Sha256 (Sign, Sign_and_Encrypt) - Aes128_Sha256_RsaOaep -
Aes256_Sha256_RsaPss
User token
policy: - Anonymouse - Username
An example
demonstrating how to use the API is available in the CODESYS Store: ‘OPC UA
Client Example’.
Additionally
it is possible to connect the OPC UA Client to an OPC UA Server within the
CODESYS IDE via the “Data Source Manager” object. OPC UA Servers can be added
online or offline.
Online:
Using the IP adress the client connects to the server and detects the existing
variables and types. The user can select the objects to be browsed.
Offline:
Using an OPC UA information model file the client reads the variables and types
from the information model. A connection to the server is not required.
