Panasonic: AC Servo Driver MBDDT2210003
Panasonic: AC Servo Driver MBDDT2210003

Alternate View



Price: (Members Only)


Availability: 2 in Stock.
Order #: MBDDT2210003
Qty:

Description Ordering Information Specifications and Drawings


Panasonic: AC Servo Driver MBDDT2210003

MINAS A4 Series, 200V


Panasonic’s MINAS A4 series corresponds to even variation of load inertia. Offers real automatic gain tuning to low and high stiffness machines with a combination of an adaptive filter. Supports the vertical axis application where the load torque is different in rotational direction. Prevents the machine from over-traveling during automatic gain tuning with over-travel detecting function. Enables you to set and check while monitoring real-time automatic gain tuning conditions on the front panel.


Features:

  • A4 Series, B Frame

  • Max. current rating : 15 A

  • Single phase

  • 200V, Load

  • Current rating: 10A
