Parker Bayside: Generation I Stealth® Helical Planetary Gearhead (PX90-010-SH Series)
Stealth PX incorporates Parker Bayside's helical planetary technology in a lower-cost package. Available in NEMA and metric frame sizes, Stealth PX delivers high torque and quiet, smooth operation for less-demanding servo applications.
Common features for all Generation I & II Stealth® gearheads:
Helical Planetary – Provides smooth, quiet operation, high torque and high accuracy.
ServoMount® – Motor-mounting design ensures error-free installation and the balanced pinion allows higher input speeds.
Precision Bearings – Provide high speed and high radial and axial load capacity.
HeliCrown® – Parker’s proprietary gear tooth geometry ensures quieter operation and higher loads than conventional gears.
Sealed Unit – Viton seals and O-Rings provide IP65 protection to prevent leaks and protect against harsh environments.
Integral Ring Gear – Cutting the ring gear directly into the housing allows for larger bearing and planet gears, delivering maximum power and stiffness in a minimum package.
Specifications:
Configuration: In-line
Frame Size: 90 mm
Gear Teeth: Helical Planetary
IP65
Nominal Continuous Torque: 220 – 278 Nm (1958 – 2474 in-lb)
Radial Load: 6000 N (1347 lbs)
Backlash arc-min: 10 – <8Model No PX90-010-SHDownloads
