Thomson: AquaTRUE™ Planetary Gearheads (AQT160 Series)

Thomson Micron® planetary gearheads are used on high precision motion control applications which require a high torque to volume ratio, high torsional stiffness, and low backlash. All of our gearheads are self-lubricating and have high radial load capacity for any given size. The ability to match inertias with our large variety of ratios, provide to keep our customers stable and controlled servo systems.

AquaTRUE™ True Planetary Gearheads

Thomson Micron introduces our new AquaTRUE gearhead design to meet the strict requirements of harsh environmental applications; such as, food and beverage handling, and packaging and dispensing. The AquaTRUE's IP66/IP67 and IP69K protection is able to handle caustic cleaning chemicals as well as high pressure washdown. This eliminates the cost of additional components such as enclosures, shielding, or mechanical transmissions. The 304 stainless steel housing eliminates the concern for rust or any type of corrosion. A laser etched permanent product label and a smooth, round external housing that is designed without any external seams or corners for bacteria to collect.

AquaTRUE Highlights

· No external seams

· 300 Series Stainless Steel

· IP66/IP67 input/output protection

· IP69K input/output protection

· NSF/ANSI 169 certification

· Corrosion resistance

· High pressure washdown

· Silicone gasket motor seal

AquaTRUE Best Applications

· Food Handling

· Water Jet Cutting

· Food Packaging

· Beverage Dispensing

· Medical Hygienic Equipment

· Pharmaceutical

· Washdown Applications

· Meat Slicing

Product Features

· Precision: 13 arc-minutes

· Frame Sizes: 160mm

· Torque Capacity: up to 876 Nm

· Ratio Availability: 3:1 thru 100:1

Model No.: AQT160-003, AQT160-004, AQT160-005, AQT160-007, AQT160-010, AQT160-015, AQT160-020, AQT160-025, AQT160-030, AQT160-040, AQT160-050, AQT160-070, AQT160-100,
