Thomson: NemaTRUE™ Planetary Gearheads (NT23/60 Series)
Thomson Micron® planetary gearheads are
used on high precision motion control applications which require a high torque
to volume ratio, high torsional stiffness, and low backlash. All of our
gearheads are self-lubricating and have high radial load capacity for any given
size. The ability to match inertias with our large variety of ratios, provide
to keep our customers stable and controlled servo systems.
NemaTRUE™ Planetary
Gearheads
Description
In addition to the standard
NEMA frame sizes. Thomson Micron now brings you a True Planetary®, RediMount
compliant gearhead that is an economical solution for your application. The
NemaTRUE has many ratios in stock for immediate delivery through the Thomson
Micron Gearhead Express program.
NemaTRUE™ Highlights
·
Sealed deep groove ball bearings provide
high radial load carrying capability
·
HRC
55-60 steel gears provide superior wear resistance and increased backlash
integrity
·
Sealed
deep groove ball bearing provides precision alignment of sun gear
·
RediMount™
system provides error-free motor installation
·
Anodized
aluminum housing reduces weight and prevents corrosion
Product Features
·
Precision: 13 arc-minutes
·
Frame Sizes: 23 (2 .3in)
·
Torque Capacity: up to 31.1 Nm
·
Ratio Availability: 3:1 thru 100:1
Model No.: NT23/60-003, NT23/60-004,
NT23/60-005, NT23/60-007, NT23/60-010, NT23/60-015, NT23/60-020, NT23/60-025,
NT23/60-030, NT23/60-040, NT23/60-050, NT23/60-070, NT23/60-100
