Crouzet: Miniature Microswitches (83137 Series)
With over 60 years’ experience in snap-action technology, Crouzet Switches offers a complete range of Microswitches for the highly demanding markets. The extensive choice consists of standard or customized Sub-subminiature, Subminiature, Miniature and Special microswitches, all conform to the most rigorous quality standards.
Our microswitches are characterized by a large range of switching ratings from 1 mA to 25 A, magnetic blowout versions for High DC ratings, sealed models, positive break versions, a wide range of operating temperatures, models for explosive atmospheres, long service life and wide variety of actuators, contact materials and fixing means.
Miniature Microswitches – Ultra Sensitive Rotary
Action with a wire
Very low operating force
Long mechanical life
Specifications
Approx body size (mm): 30x18x12
Rating (max): 6A / 250Vac
Degree of protection: IP40
Operating temperature: -20°C/+125°C
Operating force (max): 0.0012 Nm
Differential travel (max):14°
Overtravel (min): 12°
Mechanical life (cycles): 10 M
