Crouzet: Standard Limit Switches (8384 Series)
Crouzet: Standard Limit Switches (8384 Series)

Call for Pricing

Price Quote Form

Price: (Members Only)


Order #: 8384
.

Description Specifications and Drawings


Crouzet: Standard Limit Switches (8384 Series)

With its choice of casings, wide range of actuators, variety of connections and high degree of resistance to impact and splashes, Crouzet Switches offers limit switches available in the following ranges: Metal body, Plastic body, Special products and Products for severe environments. Their main characteristics are: IP6x seal, a wide range of actuators (plungers and rollers), rotary heads with momentary action, positive break contacts, compact size, etc. They also offer the option of having special levers, prewiring, connection via ISO cable glands, etc.

Standard Limit Switches

(83 840 0 Series)

  • Adjustable metal head

  • 4 positions 90°

  • Metal case

(83 840 7 Series)

  • Adjustable metal head

  • 4 positions 90°

  • Plastic or metal cases

Specifications

  • Approx body size (mm): 73x56x36

  • Housing material: Zamak

  • Actuating movement: Linear Rotary Multi direction

  • Connections: Terminals

  • Degree of protection: IP65

  • Operating temperature: -40°C / +70°C

  • Rating (max): 10A / 250Vac

  • Mechanical life (cycles): 10 M
