Delta Tau: Input/Output Board (ACC-12E)
Delta Tau: Input/Output Board (ACC-12E)



Price: (Members Only)

Quantity in Stock:1

Order #: ACC-12E
Qty:

Description Specifications and Drawings


* In overseas warehouse, about 1 week lead time for this Model.

Delta
Tau: Input/Output Board (ACC-12E)

The PMAC Accessory 12E is a general-purpose input/output board to the UMAC-Turbo and UMAC MACRO systems. ACC-12E provides 24 lines of optically isolated inputs and 24 lines of optically isolated high power outputs. The actual I/O reads and writes are carried out using M-variables. ACC-12E is one of the series of 3U rack I/O accessories designed to transfer data through the UMAC BUS (UBUS). The other boards in the family of MACRO I/O Accessory products include the following:

  • ACC-9E: 48 optically isolated inputs

  • ACC-10E: 48 optically isolated outputs, low power

  • ACC-11E: 24 inputs and 24 outputs, low power, all optically isolated

  • ACC-12E: 24 inputs and 24 outputs, high power, all optically isolated

  • ACC-14E: 48-bits TTL level I/O
