AFS/AFM60 EtherNet/IP
(Absolute Single-turn Encoders)
Description:
With its extensive self-monitoring and diagnostics possibilities the AFS60/AFM60 EtherNet/IP encoder clearly offers more when it comes to availability. With a 30-bit resolution and a highly robust, the new AFM60 absolute multiturn encoder sets new standards and the same is true for the 18-bit absolute singleturn encoder. This makes them particularly suitable for harsh application conditions in which maximum accuracy and availability are of the essence. A shaft bearing distance of 30 mm means the AFS60/AFM60 family is significantly more robust than encoders with blocked ball bearings.
The AFS60/AFM60 with EtherNet/IP interface is equipped with a configuration assembly, which makes configuration of controls significantly easier. Maximum machine availability is assured even in case of cable breakages due to the Device Level Ring (DLR) function. Additionally equipped with a multitude of diagnostics functions, the AFS60/AFM60 opens up entirely new options for the user for evaluation.
Features:
30 bit (AFM60), 18 bit (AFS60) multi-functional absolute encoders
Device Level Ring
Extensive diagnostics: Min/max values for temperature, position, speed. Operating hours counter, display of flags, alarms and warnings using e.g. a fault header (32 bit)
Status display via 5 duo LEDs
Rotary axis function
IP address via DHCP / DEC switches
Ethernet/IP interface (extended profile 0x22)
