DFS60
(Incremental Fixed Count Encoders)
Description:
The DFS60 is a high-resolution incremental encoder with a diameter of 60 mm. It offers a wide variety of customer-specific mechanical and electric adjustments. Programming of the output signal, zero pulse and resolution of up to 65,356 pulses is a unique feature for the market. The high enclosure rating, wide temperature range and large ball bearing distance make the DFS60 the ideal encoder for industrial applications in harsh environments.
Features:
Compact housing Ø 60 mm
High resolution incremental encoder family 16 bit
Number of lines from 1 ... 65,536, zero-pulse width and level of output signals programmable by customer
Universal pluggable cable outlet for radial or axial use
Connector outlets M23 and M12 available
Face mount and servo flange
Hollow shafts up to 15 mm or 5/8" or isolated variants available
Zero pulse teach possible
Reduced storage costs and downtime due to customer-specific programming
Variety of different mechanical and electrical interfaces enable the encoder to be optimally adjusted to fit the installation situation
Excellent concentricity even at high speeds
Permanent and safe operation due to a high enclosure rating, temperature resistance and a long bearing lifetime
Programmability via the PGT-08 programming software and the PGT-10-S display programming tool allow the encoder to be adapted flexibly and quickly according to customer needs
Programmable zero pulse position simplifies installation
