Galil: Single-Axis Motion Controller (DMC-3x01x Series)
Galil leverages decades of experience and technological innovation to provide motion controllers for customers across a wide range of industries. Our full product offering allows you to select the best motion controller for your specific application. Choose from single-axis or multi-axis, bus-based or stand-alone, box-level or card-level, and external drives or integrated drives. All of Galil’s motion controllers and drives are backed by a fully trained application engineering team. If our standard motion controllers don't meet your requirements we will cost-effectively make one that does. Our description of motion controller customizations will give you examples of modifications we have made to meet our customers motion requirements.
Ethernet/RS232 Single Axis Motion Controller
The DMC-30000 Motion Controller Series is Galil's latest generation single-axis motion controller. It uses a 32-bit RISC processor to provide higher speed than older models. The DMC-30000 is available as a compact card-level or box-level unit and connects to a stepper or servo motor amplifier of any power range. Or, the DMC-30000 can be purchased with an internal 800-Watt brushless sine drive or microstepping drive which minimizes space, cost and wiring. The motion controller operates stand-alone or can be networked to a PC via Ethernet.
Features
Motion controller available as card-level or box-level unit which can connect to stepper or servo amplifier of any power range
Two daisy-chainable Ethernet 100 Base-T ports. One 115kbaud RS232 port
Ethernet supports multiple masters and slaves. TCP/IP, UDP and Modbus TCP master protocol for communication with I/O devices
Encoder feedback up to 15 MHz. Quadrature standard; SSI and BiSS encoder option(SER). Sinusoidal Encoder option (DMC-31xxx). Main and auxiliary encoder inputs
Non-volatile memory for programs, variables and arrays.
Concurrent execution of four programs.
Optically isolated forward and reverse limit inputs and homing input
8 uncommitted, isolated inputs and 4 isolated outputs
High speed position latch and output compare
2 uncommitted 12bit 0-5V analog inputs (16bit ±10V inputs on DMC-31xxx) and 1 uncommitted analog output
Standard power input is +/-12V and 5V. Controller available with optional DC-DC converter with 9-48VDC single supply input.(Option for 20-80 VDC).
Single-axis motion controller with optional servo or stepper motor control in a compact enclosure:
Optional, on-board 800 W brushed/brushless sine drive; 10 A cont., 15 A peak at 20-80 VDC
160VDC input option is available, consult factory for your application requirement
Optional, on-board microstepping drive:
6 A/phase, 20-80 VDC; 256 microsteps per full step
Optional, on-board low-current stepper drive:
1.4 A/phase; Full, half, 1/4, 1/16 step; 12-30 VDC
Compact Form Factor:
DMC-30010/DMC-30011 Card: 3.0" x 4.0"
DMC-30010/DMC-30011 Box: 3.9" x 4.2" x 1.4"
DMC-30012/30014-BOX/30016-BOX/30017-BOX: 3.9" x 5.0" x 1.5"
Model No.: DMC-30010-BOX, DMC-30010-CARD, DMC-30011-BOX, DMC-30011-CARD, DMC-30012-BOX, DMC-30016-BOX, DMC-30017-BOX
