Delta: Ethernet Communication Module (DVPEN01-SL)
Delta: Ethernet Communication Module (DVPEN01-SL)


Price: (Members Only)


Order #: DVPEN01-SL
Qty:

Description Specifications and Drawings


Delta: Ethernet Communication Module (DVPEN01-SL)

DVPEN01-SL is an Ethernet communication module for remote setting and communication through WPLSoft. DVPEN01-SL is able to send E-mails, automatically correct the RTC in DVP28SV11R/T and exchange data. It supports Modbus TCP communication protocol and can conduct remote monitoring by using SCADA (Supervisory Control and Data Acquisition) software or HMI (Human Machine Interfaces).

DVPEN01-SL can be the master of Modbus TCP, sending out Modbus TCP instructions and controlling the peripheral equipment. In addition, under MDI/MDI-X auto-detection, it does not need to use a crossing cable. See the contents below for more detailed instructions on DVPEN01-SL module.

Functions

  • Auto-detects 10/100Mbps transmission speed

  • MDI/MDI-X auto-detection

  • Supports Modbus TCP protocol (at the same time supports Master and Slave mode)

  • Able to send out E-mails

  • Auto-corrects the RTC in PLC through the Internet time correction function

  • Supports point-to-point data exchange (Max. data exchange length: 200 bytes)
