Delta: Industrial Ethernet Solution (DVS-016W01-SC01 Series) Delta has just launched the Delta Industrial Ethernet Total Solution, which provides Ethernet products with enhanced hardware design, a user-friendly software interface, packet protection and compatibility with multiple industrial communication standards. With the rise of industrial automation technology and intelligent municipal engineering systems, the Ethernet, with its advantages of high speed, high stability and high compatibility, has become the most popular and widely used communication protocol. Based on Delta’s accumulated customer service experience and industrial know-how, the Delta Industrial Ethernet Total Solution helps customers construct an industrial Ethernet system that will satisfy their requirements in a wide range of applications. All of Delta’s Ethernet products are certified to UL, CE and FCC standards. Ethernet (Unmanaged) Switches: DVS-016W01-SC01 Supports IEEE802.3x full/half-duplex, auto-MDI/MDI-X.
Excellent ruggedized hardware design of 12 to 48 VDC redundant power inputs and a wide-operating temperature from -40℃ to 75℃ without the use of internal fans are providing superior reliability.
DIP switches for built-in alarm relay function, assisting network engineers with notification when port link-down and power failures occur. Supports IEEE 802.1p based QoS for packet forwarding precedence Built-in Broadcast Storm Protection Transparent transmission of VLAN tagged packets 12 to 48 VDC redundant terminal block power input Auto warning by relay output for link-down and power failure Compatible with various industrial protocols of EtherNet/IP, Profinet, EtherCAT, CC-LINK IE and DNP 3.0
Technology (Standard Compliance) Fast Ethernet Ports RJ45 Ports: 15 10/100Base-T(X), auto MDI/MDI-X, auto negotiation Fiber Optic Ports: 1 100Base-FX (SC connector), SingleMode – 30km
1 relay output Carry current 5 A@24VDC
Performance and Scalability Switching Capacity: 3.2Gbps, Wired speed, Non-blocking switching fabric Forwarding Rate: 4.8Mpps MAC Address Table: 8K Packet Buffer Memory: 1M bits Broadcast Storm Protection: Default enabled Transparent Forwarding VLAN Tagged Packets: Default enabled IEEE 802.1p based QoS: Default enabled
Input Voltage: 2 sets, 12 to 48 VDC redundant terminal block input Input Current: Max. 0.6A Overload Current Protection: Present, Max. input current 3A Reverse Polarity Protection: Present Buffer Time: Min. 13ms at 24VDC
Housing: IP40 aluminum metal case Dimensions: 145.3 mm(H) × 75 mm(W) × 108.7 mm (D) Weight: 430g Installation: Industrial DIN-Rail and wall mounting
Operating Temperature: -40℃ to 75℃(-40℉ to 167℉) Storage Temperature: -40℃ to 85℃(-40℉ to 185℉) Ambient Relative Humidity: 5% to 95%(non-condensing)
Safety: UL 508, EN 60950-1, IEC 61131-2 EMI: FCC 47 CFR Part 15 Subpart B Class B, IEC 61000-6-4, EN 55022 EMS: IEC 61000-6-2
|
|
|
 |
|
 |
|
