Panasonic: Modular High-Speed PLC (FP2SH Series)
Panasonic PLCs offer an outstanding price-performance benefit which incorporates numerous functions including PID, adaptive filters, electronic cam control, multi-axis interpolation and more, all in a very compact body. Panasonic PLCs undergo extremely rigorous testing during development that far exceeds the demands that will actually be placed on them. This is a guarantee for the long life of the product in end-use applications. Panasonic's PLC programming software, Control FPWIN Pro, was one of the first on the market conforming to the international standard IEC 61131-3. In addition to all of this, Panasonic employs highly trained application engineers that can assist in providing custom designed systems.
Specifications:
Max. 1600 inputs / 1472 outputs transistor or 400 outputs relay
Max. 184 analog inputs / 60 analog outputs
Max. 39 x RS232C or 38 x RS485/RS422 + 1 x RS232C interfaces
Program memory: 60000 to 120000 steps
Data memory: 10k to 1.000k words
PROFIBUS, Ethernet TCP/IP, Modbus, S-Link, CANopen, DeviceNet
Motion control functions
FP2SH CPU Features:
A high-performance model for high-speed operation Scanning time of 1ms for 20k steps. With an operating speed at the top of its class, super high-speed processing is made possible. The result is a dramatically decreased tact time and high-speed device.
Large programming capacity of up to 120k steps Large programming capacities of 60k and 120k are available, depending on the model.
Combine modules like building blocks I/O units, intelligent units, power supply units and backplanes can be used together for the FP2 and the FP2SH. I/O units can be located anywhere on the backplane.
Optional small PC card is also available The small PC card is available for programming backup or data memory expansion. This allows you to process great amounts of data.
Built-in comment and real-time clock functions These functions, optional with the FP2, are built right into the FP2SH.
