Glentek DC Brush Servo Motors To accommodate your complete servo system requirements, Glentek manufactures two complete series (GM and GMR) of high performance, permanent magnet DC brush servo motors which are described as follows: The GMR series utilizes high-energy Neodymium-Iron-Boron (NdFeB) magnets, which provide more torque in a smaller package with higher dynamic performance than traditional ferrite magnet designs. Due to the high torque to inertia ratio of these motors, they are ideal for applications which require high acceleration and deceleration characteristics or where the physical size of the motor is a major concern. They range in continuous torques from 16.0 lb-in (1.81 Nm) to 65.0 lb-in (7.34 Nm) and peak torques from 80.0 lb-in. (9.04 Nm) to 325.0 lb-in. (36.72 Nm). Typical applications include factory automation machinery, fitness equipment (i.e. treadmills), labeling machinery, machine tools, material handling machinery, medical equipment (i.e. CAT scanners and PET scanners), packaging machinery, printing machinery, robotics, semiconductor machinery, surface mount pick and place machines, x-y tables, textile machinery, applications which have low to medium reflected load inertias and require a high dynamic response, applications which require smooth operation and/or applications which require a lot of torque in a small mechanical form factor. High-energy Neodymium-Iron-Boron (NdFeB) magnet design provides more torque in a smaller package with higher dynamic performance than traditional ferrite magnet designs. Constructed to withstand the toughest industrial environment with rugged, high performance bearings and TENV construction with IP54 sealing standard. Optional IP65 sealing is available on 3.3" and 4.9" frame motors. Worldwide standard mounting configurations are available. Optional custom mounting configurations are available to meet virtually any requirement. Various electrical windings are available as standard to suit both low and high voltage amplifiers in order to provide optimum speed and torque characteristics. Optional custom electrical windings are available to meet virtually any requirement. Industry standard lead termination configurations (i.e. MS connectors, fluid tight strain relief cable exit, NPT hole with flying leads and terminal boxes). Optional industry standard feedback devices (i.e. high performance, low ripple 4-pole silver commutator tachometers and encoders with line driver outputs, quadrature and zero index). Standard encoder resolutions include 500 PPR, 1000 PPR, 1024 PPR, 1250 PPR, 2000 PPR, 2500 PPR, 5000 PPR and 8192 PPR. Shaft keyway standard. Class H insulation standard. Optional normally closed thermal switch is available that provides over temperature protection. Optional 24 VDC holding brakes are available. Optional precision gear reducers are available. CSA and UL recognized. CE marked.
Model No.: GMR3340-27, GMR3340-30, GMR4910-26, GMR4910-37, GMR4920-38, GMR4920-68, GMR4940-38, GMR4940-78, GMR4950-35, GMR4950-57
|
|
|
 |
|
 |
|
