Komotek :950W 220VAC Brushless Motor Without Brake,with encoder, KANZ-10BF1
Alternate View
Price:
(Members Only)
Availability:
Usually Ships in 4 to 6 Weeks
Order #:
KANZ-10BF1
Options:
KANZ-10BF1B21 [Add (Members Only)]
KANZ-10BF1N21
Qty:
Description
Ordering Information
Specifications and Drawings
E-Motionsupply is a professional servo motor supplier. Our low-voltage servo motors are produced in different countries and regions. Their quality and longevity are products that have been verified through long-term use. We accept customized orders to provide our customers with products that better suit their application needs.
KANZ Series can be applied to diverse areas of precision automation machinery such as various industrial robot systems and semiconductor manufacturing equipments.
Motor Model:
KANZ-10BF1N21
Motor Type
:
DC Brushless Servo Motor without Brake
Motor Voltage
:
220VAC
Motor Poles:8
Motor Rated Output:950W
Motor Flange Size
:
80mm
Motor Rated Phase Current
:
4.3A
Motor Peak Phase Current:18.3A
Motor Rated Torque
:
3Nm
Motor Maximum Torque:9.1Nm
Motor Rated Speed:3000RPM
Motor Maximum Speed:3500RPM
Rotor inertia:1.47x10-4kg·m2
Motor Feedback:2500lines incremental encoder
Motor Model:
KANZ-10BF1B21
Motor Type
:
DC Brushless Servo Motor without Brake
Motor Voltage
:
220VAC
Motor Poles:8
Motor Rated Output:950W
Motor Flange Size
:
80mm
Motor Rated Phase Current
:
4.3A
Motor Peak Phase Current:18.3A
Motor Rated Torque
:
3Nm
Motor Maximum Torque:9.1Nm
Motor Rated Speed:3000RPM
Motor Maximum Speed:3500RPM
Rotor inertia:1.47x10-4kg·m2
Motor Feedback:2500lines incremental encoder
With brake
Specification
