LS Mecapion: L7S Servo Drive (L7SA008)
LS Mecapion: L7S Servo Drive (L7SA008)



Price: (Members Only)


Availability: Usually Ships in 6 to 8 Weeks
Order #: L7SA008
Qty:

Description Ordering Information Specifications and Drawings


LS Mecapion: L7S Servo Drive (L7SA008)

Specifications:

  • Size: 58x169x198

  • Main power supply: 3Phase AC200 ~ 230[V]

  • Rated current: 5.2[A]

  • Peak current: 15.6[A]

  • Encoder type: Incremental encoder, 19Bit Serial encoder

  • Frequency response: Max 1kHz

  • Weight: 1.5 Kg
