RSF Elektronik: Angle Measurement (MSR 40 MKS Series)
RSF Elektronik: Angle Measurement (MSR 40 MKS Series)

Call for Pricing

Price Quote Form

Price: (Members Only)


Order #: MSR-40-MKS


Model No.:

.
Description Specifications and Drawings


RSF Elektronik: Angle Measurement (MSR 40 MKS Series)

Modular angle measurement devices with or without integral bearings establish the connection between the mechanism and the control electronics. In the field of automation, they are used both for recording the angle and position and for determining speed and acceleration values.

Modular angle measurement devices are required to convert the recorded value of a mechanical variable into electrical signals so that they can be evaluated by output devices, PLCs and industrial PCs.


MSR 40 MKS Overview

Modular angle measurement devices MSR 40 MKS without integral bearing are used as position and rotator control for electrical drives and in the measurement technology.

  • Measuring range: <360°

  • Grating pitch: 200 µm

  • Accuracy of the grating (stretched): ±30 µm/m

  • Grating carrier: steel tape scale with adhesive tape


Technical Data

  • Scale unit: steel tape scale with adhesive tape

  • Possible shaft diameters: ∅≥ 150 to 400 mm, scale-segment is pre-bent. Over ∅ 400 mm, scale-segment is not pre-bent.

  • Reference marks (RI): 25 mm from the beginning of measuring length. Additional reference marks separated by n x 100 mm.

  • Accuracy of the grating (stretched): ±30 µm/m

  • Operating temperature range: 0 °C to +60 °C

  • Storage temperature range: -20 °C to +70 °C

  • Weight (approx.): 25 g/m steel tape scale + 17 g scanning head without cable


Model No.: MSR 40.06, MSR 40.66, MSR 40.76, MSR 40.86, MSR 40.96
