Moog: Aerospace / Military Resolvers Highly Accurate Brushless Resolvers Moog brushless resolvers are economical and highly accurate. Motion feedback sensors can be used to provide velocity and position information for closed-loop electronic control, as well as brushless DC motor commutation. They contain no internal electronics or optics and are unaffected by electrical noise, heat, shock and vibration. We manufacture quality motion technology products for aerospace, military and commercial applications. Rugged, reliable - ideal for demanding environments Resolvers provide accurate position and velocity feedback as well as commutation in precision equipment, without the structural or temperature restrictions imposed by other electronic feedback devices. They are resistant to the shock and vibration levels often encountered in military and aerospace applications. These resolvers are available in standard sizes, or with custom modifications. Our engineering department is available for consultation to help tailor a resolver to fit your needs. 1, 2, 4, 8, 16, 32 and 36 speeds standard; others available 400 – 5,000 Hz frequency range standard; frequencies up to 20,000 Hz available High immunity to electrical noise Rugged design to meet demanding environments – no glass discs or optics to fail Compact design Mounts directly to shaft and housing – no coupling devices needed Brush or brushless designs High reliability – long-life design; no bearings or electronics Custom modifications available
Ideal for vertical integration with brushless motors and slip ring assemblies Commutation of brushless motors Feedback sensor for servo systems
Typical Applications (Where precise position indication is required to interface with resolver to digital converters): Model No.: SGH-78-B-2, SGH-78-C-2, SGH-78-D-2, SMH-12-A-1, SMH-14-A-1, SMH-16-J-1, SMH-17-B-3, SMH-30-B-1, SMH-30-C-1, SMH-30-E-1, SMH-32-D-1, SMH-34-C-1, SMH-34-G-1, SMH-37-A-3, SMH-37-J-1, SMH-43-E-1, SMH-53-A-1, SMVH-44-A-2, SSBH-40-C-1, SSH-12-A-2, SSH-12-D-2, SSH-23-S-1, SSH-50-B-1, SSJH-36-B-3/P195, SSJH-36-K-1, SSJH-37-J-4, SSJH-43-C-1, SSJH-46-C-1, SSJH-50-B-3, SSJH-60-A-1, SSJH-60-D-1, SSJH-63-A-1, SSJH-98-A-1
|
|
|
 |
|
 |
|
