Trust Automation Low-Power Linear Amplifier for Brushed Servo Motors (TA115 Series)
Trust Automation Linear Servo Amplifiers are the best known and most advanced products available in the industry. Our amplifier design provides superior signal reproduction and zero dead-band through the use of precision-matched and high-performance components.
For over 20 years, we have designed and manufactured drive technologies for a wide range of applications, including semiconductor processing equipment, high-speed spindle controls, robotics, vision systems, assemblies, general manufacturing, and much more. Linear amplifiers are ideal for applications requiring high bandwidth, high precision, and low electrical noise.
Since their design and production release, we have deployed tens of thousands of linear amplifiers into demanding applications. Our systems have been put to the test under real-world conditions, meeting and exceeding performance requirements with the most rigorous duty cycles.
Brush/Brushless Low to High Power:
Standard Linear Amplifiers
Trust Automation Linear Servo Amplifiers are the best known and most advanced products available in the industry. Our amplifier design provides superior signal reproduction and zero dead-band through the use of precision-matched and high-performance components.
TA115 LINEAR DRIVE FOR BRUSH SERVO MOTORS
A robust, linear amplifier, built to provide quiet and smooth power to brush motors. The Trust Automation TA115 Linear Drive is a linear servo motor amplifier designed to drive a brush motor with up to 340W of power. The TA115 is an excellent solution for voice coil type motors, high precision positioning applications and systems requiring ultra quiet driving power where low noise operation is essential. The TA115 can be operated in voltage (velocity) mode or current (torque) mode, selected via a user accessible DIP switch. Fault logic level is also selectable via DIP switch.
• Very low electrical noise
• 170W continuous/340W peak
• Integral forced-air cooling
• Digital on-the-fly gain control (DTS)
• Over-temperature protection
• Selectable current limit
