Heidenhain: CNC Controls (TNC 640 Series)

Controlling Machine Tools


For milling machines, milling/turning machines and machining centers:

  • Form a complete product line with their various features

  • Control machines with up to 18 axes

  • Their Klartext conversational programming capability is suited for the workshop floor

  • Can also be programmed externally

  • Are also suited for automated production

  • Are the correct choice for everything from simple milling procedures to high-speed milling


The contouring control for lathes:

  • Ideal for both CNC and cycle lathes

  • Enables the familiar manual production of simple workpieces

  • Supports programming with many cycles

  • Its smart.Turn feature offers form- and graphics-supported programming for complicated workpieces

  • Performs complementary milling and drilling operations in a single fixture

  • Also supports vertical lathes

  • Suited for digital or analog drive control


TNC 640 – The Contouring Control for Milling and Milling/Turning Machines

Besides milling, the TNC 640 from HEIDENHAIN is also capable of combined milling and turning operations. It is particularly well suited for milling-turning, HSC and 5-axis machining on machines with up to 18 axes. The workshop oriented and versatile control features numerous functions. It is especially attractive for the following areas of application:

  • Universal milling machines

  • Combined milling-turning machines

  • High speed milling

  • Five-axis machining with swivel head and rotary table

  • Five-axis machining on very large machines

  • Boring mills

  • Machining centers and automated machining


The optimized user interface of the TNC 640 gives you a fast overview: various color coding, standardized table editors and
smartSelect—the dialog-guided fast selection of functions—aid you at your work.


The TNC 640 features optimized motion control, short block processing times and special control strategies. Together with its uniform digital design and its integrated digital drive control including inverters, it enables you to reach very high machining speeds and the best possible contour accuracy—particularly when machining 3-D contours.


You can program turning contours with the TNC 640 in the familiar HEIDENHAIN plain language. Beyond this, you have typical contour elements for turning (recesses, undercuts, thread undercuts) as well as cycles for complex turning operations.
