Newport: Compact Motorized Actuators (TRB Series)
Newport: Compact Motorized Actuators (TRB Series)

Call for Pricing

Price Quote Form

Price: (Members Only)


Order #: TRB


Model No.:

.
Description Specifications and Drawings


Newport: Compact Motorized Actuators (TRB Series)

Features:

  • Flexible cable routing on the side

  • Slim and lightweight design

  • Integrated optical limit switches

  • Non-reflective actuator surface

  • Upgrade manual stages and mounts

The TRB motorized actuator series is the latest addition to Newport's extensive range of precision positioning actuators. The TRB provides reliable motorized linear motion in a lightweight and very compact package.

Improvements when compared to the successful TRA actuator include: higher speed, better repeatability and higher axial loading. The cable on the side, provides more flexibility for cable routing.

To provide the best fit to an application, the TRB actuators are available in open-loop stepper, closed-loop DC servo motor and integrated CONEX controller versions. To protect your investment, the TRB actuators include fixed integrated optical limit switches. These highly reliable switches also provide a basis for repeatable referencing/homing, after a shut-down, for example.

As with the TRA and CMA actuators, TRB actuators are direct replacement of micrometers which are found in a wide variety of linear and rotation stages, and are ideal for OEM applications.

Model No.: TRB12CC, TRB12PP, TRB25CC, TRB25PP, TRB6CC, TRB6PP
