LSIS: PLC (XGB Series)
Programmable logic controller(PLC) is a general-purpose control device that automatically controls machinery, facilities and assembly lines by user defined programs. It also has a variety of communication functions for sequence, motion and process control.
XGB is the micro PLC that offers maximum automation at minimum cost.
With its high performance and functionality, it can support from simple Control to complex task.
Strengthening its communication functions, XGB offers user-oriented integrated control. Based on its strengths,It can be used in many fields of applications.
XGB Expansion Module
For sensor switch, control of temperature, weight, flow, motor, actuator, and even highly precise positioning control, XGB series offer diverse special modules such as analog, HSC, and positioning to satisfy complicated industrial needs.
Features
Extensive Client Messaging Support
Encapsulated Messages, UCMM Explicit Messaging
Class 3 Connected Explicit Messaging(Server Only)
Class 1 Connected Implicit(IO) Messaging(Cyclic I/O Service Only)
EtherNet/IP Conformance Test Suite Version 2.10
100BASE-TX , 100Mbps/ Full Duplex
Max.2ea available on 1 Main Unit
No additional switch or hub (built-in switch)
Wiring reduction and flexible installation
Auto crossover function
Various diagnostic function and network status information
Communication module status
P2P status
Auto Scan function
Packet and data status
Communication module diagnosis through network
Model No.: XGB-E04A, XGB-E06A, XGB-E08A, XGB-E12A, XGB-M04A, XGB-M06A, XGB-M08A, XGB-M12A
